On Line UPS

UPS field is continuously developing. Technological Developments have brought newer and better concepts in the field. The latest trend is that of PWM technology using IGBT. ASEEM-OORJA has incorporated advanced technology in the field.

Starting from 3 KVA to 30 KVA single phase output systems and 10 KVA to 100 KVA 3 phase output systems are available.

The after Sales Service is our strong feature. We believe that Good Service retains customers and that Customer Retained is Customer Gained.

Get the ASEEM-OORJA Advantage

ASEEM-OORJA the trusted brand of the an Iso certified company in the field of UPS since 1990s. Unmatched performance, with latest technology gives you a superior edge against vagaries of power. Best known UPS for critical load application, ASEEM-OORJA is also known for prompt after sales service.

Technical Specifications

Technology	Sine PWM with IGBT & LCD / LED Display
Capacities	3.0 KVA TO 100 KVA WITH BUILT-IN ISOLATION
Input	Window	170 to 270 V AC (1PH) & 300 to 460 V AC (3 PH)
	DC Bus	96 V DC to 360 V DC
	Efficiency	Better Than 85% ( AC in - AC out )
Output	Voltage	230 V ± 1% (1 PH) & 400 V ± 1% (3 PH)
	Frequency	50 Hz ± 0.1% ( Crystal Controlled )
	Load Power Factor	0.8 Lagging to Unity
	Transient Response	O/P Overshoot & Undershoot Less than 5% at 100% Load Change.
	Distortion	Less than 5%
	Crest Factor	3:1
	Waveform	Pure Sine Wave
Protections	Input	AC Under / Over Voltage, DC Under / Over Voltage, Charging Over Current
	Output	Under / Over Voltage, Overload, Short Circuit
Indications	Mains High, Mains Low, DC High, Battery Low, Inverter ON, Output High,Output Low, Overload
Alarms	Overload, Battery Low, System Trip
Cooling	Forced Air Cooling
Generator Compatibility	Compatible to genset of any make
